CONNECTOR 126/2
In stock
Description
Product Type: PCB Screw Terminal Block
Model Series: 126 Type
Number of Positions: 2 Pin
Mounting Type: Through Hole (PCB Mount)
Connection Type: Screw Clamp
⚙️ Electrical Specifications
Rated Voltage: 250V AC
Rated Current: 10A (typical, may vary by manufacturer)
Withstand Voltage: 1500V/min
Insulation Resistance: ≥ 500MΩ
🔩 Mechanical Specifications
Pitch (Pin Spacing): 5.0 mm or 5.08 mm
Wire Range: 0.5 – 2.5 mm² (Approx. 22–14 AWG)
Screw Size: M2.5
Torque: 0.4 Nm (approx.)
🧱 Material Details
Housing Material: PA66 (Nylon)
Flammability Rating: UL94V-0
Contact Material: Brass
Contact Plating: Tin Plated
Screw Material: Steel (Zinc Plated)
🌡️ Environmental Specifications
Operating Temperature: -40°C to +105°C
Storage Temperature: -40°C to +120°C
