DB-15 Metal Dust Cover (also called DB15 Metal Hood or D-Sub Metal Shell) is used to protect and cover DB-15 male/female D-sub connectors. It provides mechanical protection, cable strain relief, and EMI/RFI shielding for industrial and communication applications. General Specifications Parameter Specification Product Name DB-15 Metal Dust Cover / Metal Hood Connector Type DB-15 D-Sub Connector Compatible Connector DB15 Male & Female Material Zinc Alloy / Metal Finish Nickel Plated / Chrome Finish Color Silver Shell Type Two-Piece Metal Hood Mounting Hardware Included Screw Type UNC 4-40 Jack Screws Cable Entry Rear / Side Entry Cable Outer Diameter Up to 7mm – 11.5mm Shielding EMI/RFI Shielded Operating Temperature -40°C to +120°C Reusable Yes Assembly Type Screw Lock Type Mechanical Dimensions (Approx.) Dimension Size Length 40 – 59 mm Width 39 – 40 mm Height 15 – 18 mm Weight 9g – 25g Features Strong metal construction Excellent EMI/RFI protection Easy two-piece assembly Includes cable clamp & screws Durable nickel-plated finish Suitable for industrial communication cables Compatible with solder and crimp DB15 connectors Applications Serial Communication Cables Industrial Control Systems VGA / Video Interfaces Automation Equipment Data Acquisition Systems Instrumentation Devices Robotics & CNC Machines Package Includes 1 × DB15 Metal Hood Mounting Screws Cable Clamp Strain Relief Hardware Common Names DB15 Metal Hood DB15 Dust Cover D-Sub 15 Metal Shell DB15 Connector Housing DB15 Backshell Specifications referenced from connector manufacturers and electronics suppliers.
