6×6×5mm Tactile Push Button Switch – Full Specification
Parameter Specification
Product Name 6×6×5mm Tactile Push Button Switch
Switch Type Momentary Tactile Switch
Actuator Type Round Button
Mounting Type Through Hole (THT/PCB Mount)
Number of Pins 4 Pins
Contact Configuration SPST Normally Open (NO)
Operation Momentary (OFF-(ON))
Body Size 6.0 × 6.0 mm
Actuator Height 5.0 mm
Total Height Approx. 7.3–7.8 mm
Rated Voltage 12 VDC
Rated Current 50 mA
Contact Resistance ≤100 mΩ
Insulation Resistance ≥100 MΩ at 100 VDC
Dielectric Strength 250 VAC for 1 Minute
Operating Force 160 ± 50 gf (Available in 100 gf, 180 gf, 260 gf options)
Travel Distance 0.25 ± 0.1 mm
Mechanical Life 100, 000 Cycles (Typical)
Electrical Life 100, 000 Cycles
Operating Temperature -25°C to +70°C
Storage Temperature -30°C to +80°C
Housing Material High Temperature Thermoplastic (PA66)
Actuator Material Nylon (Black)
Contact Material Silver-Plated Copper Alloy
Terminal Material Tin-Plated Copper Alloy
RoHS Compliance Yes
Mechanical Dimensions
Dimension Value
Body Length 6.0 mm
Body Width 6.0 mm
Actuator Height 5.0 mm
Pin Diameter 0.5 mm
Pin Pitch 4.5 mm
Overall Height Approx. 7.3–7.8 mm
Features
Compact 6×6 mm design
Soft tactile feedback
Momentary push operation
SPST Normally Open contacts
Through-hole PCB mounting
Low contact resistance
Long mechanical life
High reliability
Easy soldering
RoHS compliant
Durable silver-plated contacts
Suitable for low-voltage electronic circuits
Applications
Consumer Electronics
PCB Control Boards
DIY Electronic Projects
Industrial Equipment
Power Supply Controls
Home Appliances
Remote Controls
Computer Peripherals
Audio & Video Equipment
Medical Devices
Instrumentation
Automation Systems
IoT Devices
Embedded Systems
Electronic Toys
Package Contents
1 × 6×6×5mm Tactile Push Button Switch (4-Pin)
Keywords (SEO)
6×6×5mm Tact Switch
Tactile Push Button Switch
4 Pin Tactile Switch
PCB Push Button Switch
Momentary Push Button
SPST NO Tact Switch
Through Hole Tact Switch
Electronic Push Switch
Micro Tactile Switch
PCB Mount Push Button
This specification is suitable for an e-commerce listing or product catalog for Switch Mart India.
