The connector shown in the image is a PCT-SPL-62 Spring Lever Wire Connector, designed for fast, secure, and reusable electrical wire connections. It features 6 input terminals and 2 common output terminals, making it ideal for parallel wiring and power distribution.
General Specifications
Parameter Specification
Product Name PCT-SPL-62 Lever Wire Connector
Model PCT-SPL-62
Connector Type Spring Lever Wire Connector
Configuration 6 Input × 2 Output (6:2 Pole)
Number of Conductors 8 Conductors
Reusable Yes
Mounting Type Inline Cable Connector
Locking Mechanism Lever Lock
Electrical Specifications
Parameter Specification
Rated Voltage 250V AC (Impulse Voltage: 4kV)
Maximum Operating Voltage Up to 400V
Rated Current 32A
Maximum Power 7kW
Frequency 50/60Hz
Wire Compatibility
Wire Type Supported Size
Solid Wire 0.08–2.5 mm²
Flexible Wire 0.08–4.0 mm²
AWG Range 28–12 AWG
Recommended Strip Length 10–12 mm
Material
Component Material
Housing Flame-Retardant Modified Nylon (PA66)
Spring Stainless Steel
Conductor Nickel/Tin-Plated Copper Alloy
Lever High-Strength Engineering Plastic
Mechanical Specifications
Parameter Approximate Value
Length 40 mm
Width 30 mm
Height 15 mm
Color Grey Body with Orange & Blue Levers
Weight Approximately 10–13 g
Operating Conditions
Operating Temperature: -20°C to +80°C
Maximum Continuous Service Temperature: 85°C
Flame-retardant insulating housing
Corrosion-resistant contacts
Vibration-resistant connection
Features
Tool-free lever operation
Quick wire insertion and removal
Reusable multiple times
Strong spring clamping force
Secure, maintenance-free electrical connection
Compact design for junction boxes
Supports solid, stranded, and flexible conductors
Low contact resistance
High electrical reliability
Easy wire inspection
Applications
Electrical distribution boxes
LED lighting installations
Industrial control panels
Home and commercial wiring
Automation systems
HVAC equipment
Solar power installations
Junction boxes
Machinery wiring
DIY electrical projects
Package Contents
1 × PCT-SPL-62 Lever Wire Connector (6 IN 2 OUT)
Advantages
Fast installation
No screws or crimping required
Reusable and cost-effective
Safe and reliable wire connection
Compact, space-saving design
Suitable for residential, commercial, and industrial applications
This specification is suitable for a Switch Mart India product catalog, e-commerce listing, or SEO product page.
