The ELCOM MPS-1 is a panel-mount, shrouded-cap, momentary micro switch with SPDT (1NO + 1NC) contacts, rated at 4A, 250VAC. It is commonly used in control panels, UPS systems, automation equipment, instrumentation, and electronic assemblies.
Key Specifications
Model: MPS-1
Brand: ELCOM
Switch Type: Shrouded Push Button Micro Switch
Contact Arrangement: SPDT (1NO + 1NC)
Current Rating: 4A
Voltage Rating: 250VAC
Contact Resistance: 20 mΩ Max
Insulation Resistance: 100 MΩ Min
Dielectric Strength: 1KV AC for 1 Minute
Mechanical Life: 50, 000 Cycles
Electrical Life: 10, 000 Cycles
Operating Temperature: -20°C to +85°C
Terminal Type: Solder Type
Available Actuator Colors: Red, Black, Green
